Product Details
Ports & interfaces
Connectivity technology
Wired
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB Power Delivery
Y
USB Power Delivery revision
3.0
USB Power Delivery up to
100 W
HDMI ports quantity
1
HDMI version
2.0
Microphone in
N
Network
Ethernet LAN
Y
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Networking standards
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u
Full duplex
Y
Performance
Data transfer rate
5 Gbit/s
HD type
4K Ultra HD
Maximum digital resolution
4096 x 2160 pixels
Product colour
Grey
High Dynamic Range 10 (HDR10)
Y
LED indicators
Y
UASP support
Y
Housing material
Aluminium
Power
Power source type
USB
Power consumption (typical)
15 W
Software
Windows operating systems supported
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Linux operating systems supported
Y
Mobile operating systems supported
Android, iPadOS
Other operating systems supported
Chrome
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
5 - 90%
Sustainability
Sustainability certificates
CE
Weight & dimensions
Width
427 mm
Depth
50 mm
Height
12 mm
Weight
70 g
Packaging data
Package width
170 mm
Package depth
142 mm
Package height
30 mm
Package weight
200 g
Packaging content
Quick start guide
Y
Logistics data
Products per master (outer) case
24 pc(s)
Master (outer) case width
320 mm
Master (outer) case length
380 mm
Master (outer) case height
220 mm
Other features
Cable length
0.3 m
Chipset
VIA - VL102, VIA - VL817, Realtek - RTL8153, Realtek - RTD2172A, Terminus Tech - FE1.1S
