Technical details

Compliance certificates

CE, RoHS

Sustainability certificates

CE, RoHS

Logistics data

Harmonized System (HS) code

84733080

Master (outer) case width

320 mm

Master (outer) case length

500 mm

Master (outer) case height

210 mm

Products per master (outer) case

70 pc(s)

Features

Cable length

1 m

Connector 1

HDMI Type A (Standard)

Connector 2

HDMI Type A (Standard)

Connector 1 gender

Male

Connector 2 gender

Male

Connector 1 form factor

Straight

Connector 2 form factor

Straight

Product colour

Black

HDMI version

1.4b

3D

Y

Supported graphics resolutions

1920 x 1080 (HD 1080),3840 x 2160,4096 x 2160

Dolby technologies

Dolby Digital Plus,Dolby TrueHD

Audio Return Channel (ARC)

Y

HDMI Ethernet channel

Y

HDCP

Y

HDCP version

1.4

Data transfer rate

10.2 Gbit/s

Maximum refresh rate

120 Hz

AWG wire size

28

Connector contacts plating

Gold

Cable jacket material

Polyvinyl chloride (PVC)

Weight & dimensions

Weight

95 g

Package width

200 mm

Package depth

220 mm

Package height

21 mm

Package weight

100 g
