Technical details

Harmonized System (HS) code

85176990

Features

Converter type

Active video converter

LED indicators

Power

Product colour

Black

Housing material

Steel

Certification

CE, FCC, RoHS

Video

Maximum video resolution

1920 x 1200 pixels

Maximum refresh rate

60 Hz

Audio

Audio output channels

5.1 channels

Audio support

Y

Ports & interfaces

Host interface

HDMI

Output interface

DisplayPort

Power

External power adapter

Y

Input voltage

100 - 240 V

Operating voltage

5 V

Operating current

2 A

Power consumption (typical)

5 W

Input current

0.5 A

Power plug type

Type N

Operational conditions

Operating temperature (T-T)

0 - 70 °C

Storage temperature (T-T)

-10 - 80 °C

Operating relative humidity (H-H)

5 - 90%

Weight & dimensions

Width

43 mm

Depth

82 mm

Height

23 mm

Weight

109 g

Packaging data

AC adapter included

Y

Included power plug types

ANZ,AU,EU,NA,UK

Manual

Y

Package width

227 mm

Package depth

156 mm

Package height

54 mm

Package weight

392 g
