Product Details
Ports & interfaces
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-B
Hub interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
Ports quantity
5
DC-in jack
Y
Features
Data transfer rate
5000 Mbit/s
Product colour
Black
Housing material
Aluminium
LED indicators
Power
Hot-swap
Y
Cable length
0.1 m
Plug and Play
Y
Certification
CE, FCC, RoHS, REACH
Power
Power consumption (typical)
24 W
Input voltage
100 - 240 V
Input current
0.6 A
Output voltage
12 V
Output current
2 A
Power plug type
Type M
Weight & dimensions
Width
60 mm
Depth
100 mm
Height
26 mm
Weight
135 g
Packaging data
Package width
98 mm
Package depth
150 mm
Package height
95 mm
Package weight
535 g
Packaging content
AC adapter included
Y
Included power plug types
ANZ, EU, JP, NA
Cables included
USB
Wall mounting kit
Y
Quick installation guide
Y
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Storage temperature (T-T)
-20 - 50 °C
Operating relative humidity (H-H)
20 - 80%
Logistics data
Master (outer) case width
315 mm
Master (outer) case length
315 mm
Master (outer) case height
335 mm
Products per master (outer) case
18 pc(s)
Other features
Chipset
Realtek - RTS5411
