Printing

Maximum resolution

240 x 144 DPI

Maximum printing width (columns)

136

Colour

N

Maximum print speed

1550 cps

Maximum print speed (draft)

1320 cps

Maximum print speed (LQ)

330 cps

Character pitch

10,12 cpi

Maximum number of copies

10 copies

Built-in barcodes

Code 39,POSTNET,UPC-A,UPC-E

Paper handling

Maximum print size

A4 (210 x 297 mm)

Paper tray media types

Labels

Features

Buffer size

128 KB

Sound pressure level (printing)

58 dB

Page description languages

ESC P,PPDS

Country of origin

Japan

Ports & interfaces

Standard interfaces

Parallel, RS-232, USB 2.0

Optional connectivity

Ethernet

Endurance

Print head

9-pin

Print direction

Bi-directional

Print head life

200 million characters

Ribbon life (black, draft)

15 million characters

Mean time between failures (MTBF)

20000 h

Technical details

Harmonized System (HS) code

84433210

Power

Power consumption (typical)

185 W

Power consumption (standby)

75 W

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Operating relative humidity (H-H)

10 - 80%

System requirements

Windows operating systems supported

Windows 2000,Windows 7,Windows 8,Windows 98,Windows XP

Bundled software

Epson Status Monitor

Weight & dimensions

Width

700 mm

Depth

378 mm

Height

363 mm

Weight

34 kg

Packaging data

Quantity per pack

1 pc(s)

Package width

485 mm

Package depth

840 mm

Package height

505 mm

Package weight

35.5 g

Other features

Connectivity technology

Wired

Print technology

Dot matrix

Needles

36 (4 x 9)

Logistics data

Products per pallet

4 pc(s)

Pallet gross width

120 cm

Pallet gross height

100 cm

Products per pallet layer

1 pc(s)

Products per pallet layer (UK)

2 pc(s)

Products per pallet (UK)

8 pc(s)

Pallet length (UK)

120 cm

Pallet width (UK)

100 cm

Pallet height (UK)

2.1 m
